Electrical
Nominal input voltage : 24Vdc, 48Vdc, 110Vdc, 220Vdc, 240Vdc
Operating input voltage range : 20-30Vdc (24Vdc), 40-60Vdc (48Vdc), 93-143Vdc (110Vdc), 186-286Vdc (220Vdc),
198-302Vdc (240Vdc)
Nominal output frequency : 50/60Hz ± 0,1%
Output power : 1kVA, 1.5kVA or 2kVA / inverter module, max. 4 modules/shelf*
Power factor : > 0.8
Efficiency : 87%
Output nominal voltage : 110/115/120Vac, 220/230/240Vac
Voltage regulation : ± 2%
Crest factor : 3:1
Dynamic response time : < 20ms
Isolation
– AC – DC : 2000Vrms
– DC – Ground : 2000Vrms
– AC – Ground : 2000Vrms
THD : < 3% linear load, < 5% non linear load
Overload : 150% – 1 min, 125% – 10 min min%MCEPASTEBIN%
The 24Vdc input inverter is available only in 1kVA version.
Automatic Transfer Switch
AC voltage range : -25% to +20% Nominal Vin
Frequency range : 45 to 65Hz
Operating modes : online (load supplied by inverter) and offline (load supplied by AC mains)
Transfer time : 5-8ms
User interface
LCD display with 2 x 16 characters
Inverter module LED indicators : Fault, Load level
Dry contacts : Overload, Line Fail, Low DC Voltage, Inverter Fault
Serial port RS232 or RS485
Environmental
Operating temperature : -10 to +50°C, with linear power derating above 40°C
Storage temperature : -40 to +85°C
Humidity : 0 to 95% RH non-condensing
Altitude : -500 to +2800m
Cooling : Forced air
Ingress protection rating : IP20
Physical dimensions
Shelf 19″ 3U / W443.5 x H133.5 x D498.9 mm, 7kg
Inverter module : 4kg
Monitor module : 3kg
Protection
Reversed polarity
Over-temperature
Overload
Output shortcircuit
DC (Battery) overvoltage
DC (Battery) undervoltage
Bypass overvoltage
Bypass undervoltage
Agency Compliance
Safety
– EN 60950-1, CE Marked to LVD 2006/95/EC
Emissions
– EN55022
– EN61000-3-2
– EN61000-3-3
– EN55024
Immunity
– EN 61000
